UL2661 AWG18x3C OD5.5, 105C 300V, UV & Oil Resistant

Brand Name : WCH Cable

Model Number : UL2661 AWG18x3C

Certification : UL & CUL Certificate

Place of Origin : Dongguan, China

MOQ : 5000 meters

Price : USD0.2012

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000000 meters per month

Delivery Time : 9 days for ready goods

Packaging Details : 305 meters per reel

UL Type : 2661

Application : Power Cord Cable

Conductor Gauge : 18AWG

Diameter : 5.50mm

Jacket Material : Special Made PVC

Colour : Black

Contact Now

UL2661 AWG18x3C OD5.5, 105C 300V, UV & Oil Resistant

Conductor Specification (AWG) 18
Section Area (mm²) 0.824
Material 　 Tinned Stranded Copper
Configuration (mm) TS41/0.16±0.007
Conductor Quantity 　 3C
Insulation Average Thickness (mm) 0.29
Minimum Thickness (mm) 0.24
Over Diameter (mm) 1.80±0.10
Material 　 Special Made PVC (RoHS)
Colour 　 Black, Red, Yellow
Jacket Average Thickness (mm) 0.81
Minimum Thickness (mm) 0.61
Overall Diameter (mm) 5.50±0.20
Material 　 Special Made PVC (RoHS)
Colour 　 Black
Electrical
Capability		 Rated Temperature (℃) 105
Rated Voltage (V) 300
Rated Currency (A) --
Conductor Resistance (Ω/KM 20℃) 23.2
Insulation Resistance (MΩ/KM 20℃) 10
Flammability Fire Retardance 　 VW-1
　 　 CUL FT1
Approval UL Style Number 　 2661
Reference Standard 　 758
Environmental Standard 　 Lead Free
　 　 RoHS & Reach Compliant
