TPU Cable UL20280 22AWG 4Cores OD4.7mm Matt Black (PVC Wire)

Product Categories
WCH Cable Industrial Co., Ltd.
Contact Now

TPU Cable UL20280 22AWG 4Cores OD4.7mm Matt Black (PVC Wire)

Brand Name : WCH Cable

Model Number : UL20280

Certification : UL, Cul, AWM

Place of Origin : Dongguan, China

MOQ : 3050 meters

Price : USD0.175 per meter

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000000 meters per month

Delivery Time : 9 days for ready goods

Packaging Details : 305 meters per reel

UL Style : 20280

Gauge : 22AWG

Cores Quantity : 4C

Overall Diameter : 4.70mm

Insulation : PVC

Jacket Material : TPU

Contact Now

TPU Cable UL20280 22AWG 4Cores OD4.7mm Matt Black (PVC Wire)

Conductor Specification (AWG) 22
Section Area (mm²) 0.3418
Material 　 Tinned stranded copper
Configuration (mm) TS17/0.16±0.007
Insulation Ave Thickness (mm) 0.26
Min Thickness (mm) 0.20
Over Diameter (mm) 1.30±0.10
Material 　 PVC (RoHS)
Colour 　 White, Black, Red, Yellow
Jacket Ave Thickness (mm) 0.78
Min Thickness (mm) 0.61
Over Diameter (mm) 4.70±0.20
Material 　 Polyurethane TPU (RoHS)
Colour 　 Black
Surface Effect 　 Matt
Electrical
Capability		 Rated Temperature (℃) 80
Rated Voltage (V) 300
Conductor Resistance (Ω/KM 20℃) 59.4
Insulation Resistance (MΩ/KM 20℃) 10
Approval UL Style Number 　 20280
CSA Grade 　 I/II A
Environmental Standard 　 Lead Free
　 　 RoHS & Reach Compliant

Spec Download: UL20280, UL20280 specification
