UL20080 Low Voltage PVC Flat Ribbon Cable Rated 60, 80, 90 or 105 deg C 30V

Product Categories
WCH Cable Industrial Co., Ltd.
Contact Now

UL20080 Low Voltage PVC Flat Ribbon Cable Rated 60, 80, 90 or 105 deg C 30V

Brand Name : WCH Cable

Model Number : UL20080

Certification : UL Certificate

Place of Origin : Dongguan, China

MOQ : 1220 meters

Price : 0.12 per meter

Payment Terms : D/P, L/C, D/A, D/A, T/T, Western Union, MoneyGram

Supply Ability : 500,000 meters per month

Delivery Time : 9 days for ready goods

Packaging Details : 152.5 meters per reel

Approval Style : UL20080

Conductor Material : High Purity Copper Wires

Rated Temperature : 60, 80, 90 or 105 deg C

Insulation Material : Polyvinyl Chloride PVC

Rated Voltage : 30V Low Voltage

Conductor Size : 16-28AWG

Contact Now

UL20080 Low Voltage PVC Flat Ribbon Cable Rated 60, 80, 90 or 105 deg C 30V

Style Description: UL20080, Flat Cable, Flat Ribbon Cable, PVC Flat Cable

Rating: 60, 80, 90 or 105 deg C, 30 Vac, VW-1 flame.

Insulation Material: Extruded PVC.

Standard: Appliance Wiring Material UL 758.

Application: Internal Wiring of Class 2 Circuits in Audio, Video and Electronic Equipment.

Style Number Conductor Structure Pin Quantity Insulation Thickness Overall Diameter Conductor Resistance
AWG No/mm Pin mm mm Ω/KM
UL20080 28 7/0.127 2 0.40 1.10x2.20 239.00
28 7/0.127 3 0.40 1.10x2.30 239.00
28 7/0.127 4 0.40 1.10x4.40 239.00
26 7/0.16 2 0.40 1.30x2.60 150.00
26 7/0.16 3 0.40 1.30x3.90 150.00
26 7/0.16 4 0.40 1.30x5.20 150.00
24 11/0.16 2 0.40 1.45x2.90 94.20
24 11/0.16 3 0.40 1.45x4.35 94.20
24 11/0.16 4 0.40 1.45x5.80 94.20
22 17/0.16 2 0.40 1.60x3.20 59.40
22 17/0.16 3 0.40 1.60x4.80 59.40
22 17/0.16 4 0.40 1.60x5.60 59.40
20 21/0.178 2 0.40 1.85x3.70 36.70
20 21/0.178 3 0.40 1.85x5.55 36.70
18 34/0.178 2 0.40 2.10x4.20 23.20
18 34/0.178 3 0.40 2.10x6.30 23.20
16 26/0.25 2 0.40 2.40x4.80 14.60
16 26/0.25 3 0.40 2.40x7.20 14.60

WCH Cable - Professional Manufacturer of Ribbon Cable, UL Cord, Cable Assembly

UL20080 Low Voltage PVC Flat Ribbon Cable Rated 60, 80, 90 or 105 deg C 30V

UL20080 Low Voltage PVC Flat Ribbon Cable Rated 60, 80, 90 or 105 deg C 30V

UL20080 Low Voltage PVC Flat Ribbon Cable Rated 60, 80, 90 or 105 deg C 30V

UL20080 Low Voltage PVC Flat Ribbon Cable Rated 60, 80, 90 or 105 deg C 30V

UL20080 Low Voltage PVC Flat Ribbon Cable Rated 60, 80, 90 or 105 deg C 30V

UL20080 Low Voltage PVC Flat Ribbon Cable Rated 60, 80, 90 or 105 deg C 30V

UL20080 Low Voltage PVC Flat Ribbon Cable Rated 60, 80, 90 or 105 deg C 30VUL20080 Low Voltage PVC Flat Ribbon Cable Rated 60, 80, 90 or 105 deg C 30V

Tag: UL20080, flat ribbon cable
